Specifications | |
---|---|
Built/yard | 1989 |
Classification | Bureau Veritas, I ✠, Hull ✠, Dredger Coastal Water, ✠ AUT-UMS, MON SHAFT, ✠ MACH, valid until June 2029 |
Dimensions | 99.00 x 17.35 x 8.60 m |
Draft | 6.20 m |
GT/NT | 3498/1049 |
Propulsion | single screw, Mirrlees Blackstone diesel engine, type K Major MK3, output 2,940 kW, C.P.P. |
Speed | approx. 12.5 knots |
Generators | 4,000 kVA, driven by main diesel engine 650 kVA, driven by caterpillar diesel engine, type 3508B DI-TA |
Hopper capacity | approx. 2,800 m3 / 6,300 tons |
Trailing pipe | diam. 850 mm, swell compensated |
Dredging depth | 33.00 m |
Dredge pump | make: IHC, electr. driven, 2,200 kW |
